Complete rotary capping head (cap-tightening head) for a three-in-one (rinse-fill-cap) beverage filling machine: the drive shaft, magnetic torque-limit clutch, cap-grip jaws and cam assembly that pick up a loose cap, screw it onto the bottle and release it without over-tightening.
Specifications
| Function | Picks up, screws on and releases the bottle cap in one capping-machine station |
|---|---|
| Torque control | Magnetic clutch slips at a set torque once the cap seats, so caps are tightened consistently without crushing the thread |
| Drive | Synchronized to the capping turret by gear/cam, matching the machine’ds rotation speed |
| Material | Stainless steel and hardened alloy wear parts |
| Fit | Made to your machine’s head-mount dimensions and cap size — send the mount drawing or a sample head when ordering |
Frequently asked questions
Will this capping head fit my filling machine?
Capping heads are not a universal part — the mounting, shaft length and cap-grip size are specific to each filling-machine model. Send us your machine brand/model, the head’s mounting dimensions or a photo of the part you are replacing, and we confirm fit before producing it.
Can the torque be adjusted for different cap sizes?
Yes, the magnetic clutch’s slip torque is set to the cap size and material you specify when ordering.
